| Brand Name : | DFSK |
| Model Number : | DFSK ec35/ec36 |
| Certification : | EEC/COC |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 70000 units per year |
| Delivery Time : | 10-15 working days |
Specification
| Item | L1(LHD) | R1(RHD) | ||
Basic | Optional | Basic | Optional | |
Gotion (Lithium Iron Phosphate) | Gotion (Lithium Iron Phosphate) | |||
Basic Parameter | ||||
| Length × Width × Height (mm) | Box van:4500*1680*1985 | Box van:4500*1680*1985 | ||
Wheelbase (mm) | 3050 | 3050 | ||
Wheel tread (mm) | 1435/1435 | 1435/1435 | ||
Curb weight (kg) | 1510 | 1510 | ||
Gross weight kg | 2600 | 2600 | ||
| Acceleration time of 0-50km/h | ＜10S | ＜10S | ||
| Acceleration time of 50-80kW/h | ＜15S | ＜15S | ||
Max Speed (km/h) | 80 | 100 | 80 | 100 |
Seating capacity | 2 | 2+2 | 2 | 2+2 |
Electric drive and rear axle | ||||
| Motor Type | Greatland: TZ210XSR41/Permanent Magnet Synchronous Motor | Greatland: TZ210XSR41Permanent Magnet Synchronous Motor | ||
Motor Cooling Method | Water cooling | Water cooling | ||
| Rated Power/Peak Power (KW/rpm) | 30/3600—60/9000 | 30/3600—60/9000 | ||
| Rated torque / Peak torque(N.m) | 80/200 | 80/200 | ||
Drive axle speed ratio | 10.5 | 10.5 | ||
Estimated Range [WLTP] | Max. speed 80:268km | Max. speed 100:163km | Max. speed 80:268km | Max. speed 100:163km |
Voltage | 307.2 | 307.2 | ||
Battery capacity kWh | 38.7 standard:With heating and maintenance switch | 38.7 standard:With heating and maintenance switch | ||
OBC power | 6.6KW | 6.6KW | ||
Transmission/Reducer | NA | NA | ||
System structure | ||||
Body Type | Integral body | Integral body | ||
Drive Mode | Rear egine, rear drive | Rear egine, rear drive | ||
Front Suspension | MacPherson Independent Suspension | MacPherson Independent Suspension | ||
Rear Suspension | Non-independent 5-leaf-spring suspension | Non-independent 5-leaf-spring suspension | ||
Brake | Front disc and rear drum, Mechanical Parking Brake | Front disc and rear drum, Mechanical Parking Brake | ||
Steering Type | EPS | EPS | ||
External Configuration | ||||
Tire | 185R14LT 8PR | 185R14LT 8PR | ||
Tire Rim | Silver steel wheel( optional black steel spare tire ) | Silver steel wheel( optional black steel spare tire ) | ||
| Wheel Cover | Steel wheel decoration cover (DFSK logo) | Steel wheel decoration cover (SOKON logo) | Steel wheel decoration cover (DFSK logo) | Steel wheel decoration cover (SOKON logo) |
Wheel Nut | Galvanized nuts | Galvanized nuts | ||
Front/Rear Bumper | the same color | the same color | ||
Grille | same color | same color | ||
Front/rear mudguard | IA,without logo | IA,without logo | ||
| Front combination headlight | European standard regulation requirements: automatic headlight lighting function | European standard regulation requirements: automatic headlight lighting function | ||
Front fog light | IA | IA | ||
Daytime running light | European standard regulation requirements:IA | European standard regulation requirements:IA | ||
Side turn signal | White lamp shade and yellow light bulb | White lamp shade and yellow light bulb | ||
Wiper | Front wiper( with bone ) | Front wiper( with bone ) | ||
| Exterior Rear view Mirror | Standard type, matt black, external manual adjustment | Electric Exterior Rearview Mirror | Standard type, matt black, external manual adjustment | Electric Exterior Rearview Mirror |
Sunroof | NA | NA | ||
Outer handle | Matt black | Matt black | ||
| Glass | 2 seats:lift glass for front door,panel for middle sliding door/rear side ；glass for back door | 2 seats:lift glass for front door,panel for middle sliding door/rear side ；glass for back door | ||
| 4 seats:lift glass for front door,glass for middle door;glass for back door,panel for rear side | 4 seats:lift glass for front door,glass for middle door;glass for back door,panel for rear side | |||
"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional,
and "-" - indicates that there is no such configuration;
