EC31 RHD Mini Truck Specification
Model | EC31 Small Flatbed Truck |
Basic Parameter | |
Size (mm) | 4730*1670*1960 |
Wheelbase (mm) | 3050 |
Wheel tread (mm) | 1410/1410 |
Curb weight (kg) | 1320 |
Gross weight (kg) | 2600 |
Acceleration time of 0-50 km/h | ＜10 Sec |
Acceleration time of 50-80 kW/h | ＜10 Sec |
Max speed (km/h) | 80 |
Seater | 2 |
Electric Drive and Rear Axle | |
Motor Type | Permanent Magnet Synchronous Motor |
Motor cooling method | Water cooling |
Rated Power (kW/rpm) | 30/3600-60/9000 |
Rated Torque (N.m) | 80/200 |
Drive axle speed ratio | 10.5 |
Estimated Range (WLTP) | 215 km |
Voltage(V) | 307.2 |
Battery Rated Energy | 38.7kWh |
Battery type | Lithium iron phosphate |
Transmission/Reducer | Single-spped Automatic |
External Configuration | |
Tire | 185R14LT 8PR |
Tire Rim | Silver Steel Wheel, Steel Spare Tire (silver) (5 bolts) |
Wheel Cover | Steel wheel decoration cover with DONGFENG Logo |
Front/Rear Bumper | Body color, black middle grille |
Front combination headlight | New style: electric height adjustment with automatic headlights |
Front fog lights | ● |
Daytime running lights | ● |
Side turn signal | White lamp shade and yellow light bulb |
Full car glass | Electric lift glass for the front door, glass for rear side |
Glass lifter | Electric lift |
Rear combination lights | Double Reverse Lights & Double Fog Lights, Rear combination light strip |
External spray pattern decoration | Customizable |
Internal configuration | |
interior style | Black interior |
Inside rearview mirror | Double visors,front passenger seat with make-up mirrior |
| Audio-visual system | MP5 with DAB,Multilingual (only MP5 function available, no information of electric vehicles) |
Air Conditioning | Single steam |
Shift control mechanism | Knob type (SOKON Logo) |
Description of seats | New design, Semi-enclosed cushion, fabric:M085+M086 |
Seat belt and cover | Nissan Black, front seat: 3 points, back row: NA |
System Structure | |
Body Type | Short head, Single row, Non-reversible |
Drive Mode | Rear egine, rear drive |
Steering Type | EPS |
Front Suspension | Mac pherson independent suspension |
Rear Suspension | Non-independent 6-leaf-spring top mounted |
Security, Intelligence | |
Airbag | Airbag for driver seat |
Reversing video image | MP5 has reversing image |
Central control | Front door with remote central control |
Reversing radar | NA |
ABS anti-lock braking | ● |
Manual air conditioning | ● |
Spare wheel | ● |
Vehicle tools | ○ |
Charging gun | ○ |
Tire pressure monitoring system (TPM) | ● |
| Slow charge | European standard fast and slow charging integrated, European standard charging port |
| Fast charge | European standard fast and slow charging integrated, European standard charging port |
Body description | |
Cargo box (guardrail, railing) | 2.9m square tube cargo box(Inner size: 2900×1540×350) |
Others | |
| Visual standard parts (including the visual range with five doors and one cover open) | Environmentally friendly |
“●”——Indicates that this configuration is available, “○”——Indicates that this configuration is optional,
“-”——Indicates that this configuration is not available
DFSK EC31 EV Tiny Electric Truck Picture
DFSK EC31 Electric Small Flatbed Truck Large Cargo Space, Cargo size is 4730*1670*1960
DFSK EC31 Small Electric Trucks 275km Mile Range Per Charging
DFSK EC31 Small Electric Trucks Fast Charging, Approved for Fast Charging,90 mins
