DFSK Electric Trucks RuiChi EC31 243.67 Cu.ft. Small Cargo Box Truck
Specification
Ruichi EC31 Mini Truck | ||
Item | EC31 Box Cargo (Corrugated) | EC31 Refrigeration |
Basic | ||
Size (mm) | 4710×1635×2460 | 4735×1635×2440 |
Body Type | load-bearing body | |
Body | ||
Length (mm) | 4710 | 4735 |
Width (mm) | 1635 | 1635 |
High (mm) | 2460 | 2440 |
Wheel tread (mm) | 3050 | |
Front Wheelbase (mm) | 1410 | |
Rear Wheelbase (mm) | 1410 | |
Curb weight (kg) | 1425 | 1570 |
Door | 2 | |
Seat | 2 | |
Cargo Size (mm) | 2770×1550/1570×1610 | 2660×1450×1430 |
Van cargo volume (m³) | 6.9/7.0 | 5.5 |
Rated load mass (kg) | 1045 | 900 |
Max Speed (km/h) | 80 | |
Approach angle (°) | 30 | |
Departure angle (°) | 35 | |
Power | ||
Motor type | Permanent magnet synchronous motor | |
Battery type | Lithium Iron Phosphate | |
Total motor power (kw) | 60 | |
Total motor torque | 220 | |
Number of drive motors | 1 | |
Motor layout | Horizontal | |
Operating mileage (CLTC) | 275 | |
Operating mileage (NEDC) | / | |
Battery capacity | 38.64 kWh (AVIC Battery) | |
Battery heating function | ● | |
Chassis steering | ||
Drive mode | RWD | |
Front suspension type | MacPherson independent suspension | |
Rear suspension type | Longitudinal leaf spring non-independent suspension | |
Assist type | Electronic Assistance (EPS) | |
Body structure | load-bearing body | |
Wheel brake | ||
Front brake type | Disc brakes | |
Rear brake type | Drum brake | |
Parking brake type | Mechanical | |
Front Rear tire specifications | 185R14LT 8PR | |
Active/passive safety equipment | ||
Passive pedestrian protection device | Seat belt | |
Seat belt not fastened reminder | ● | |
ABS anti-lock | ● | |
Braking force distribution (EBD/CBC, etc.) | ● | |
External/anti-theft configuration | ||
Central locking in car | ● | |
Front/rear electric windows | Front | |
Remote key | ● | |
Multimedia configuration | ||
Number of speakers | 2 | |
Lighting configuration | ||
Headlight | Halogen | |
Headlight height adjustable | ● | |
Seat configuration | ||
Driver/Passenger seat adjustment form | Backrest adjustment | |
Air | ||
Air conditioning temperature control method | ●Manual | |
"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional, and "-" - indicates that there is no such configuration;
Ruichi EC31 Small Cargo Box Truck Description
Anout RUICHI EC31: Ruichi EC31 mainly has two models: cargo box and refrigerated truck, AVIC battery, 38.64kWh, 275KM range. 2 seats, 243.67 cubic feet small cargo box truck, the two models have different body and cargo box sizes to meet the transportation needs of different sizes of goods.
